True Oak® Deep is manufactured in any length and is supplied from a wide selection of unpainted substrates or pre-painted Colorcote, Colorsteel and pre-painted aluminium coatings. True Oak® Deep is exclusive to Roofing Industries and as an extremely difficult product to roll-form, required the very latest in advanced manufacturing technology in bringing the product to reality. As a forerunner to True Oak® Deep — True Oak® Corrugate has already been readily accepted and widely used by specifiers throughout the country particularly taking into consideration the benefits of lower pitch, versatility, spanning, physical strength and finally aesthetics. It is expected True Oak® Deep will be equally as popular.
Get in touchDisplays a wider effect of the seam providing a striking appearance in both roofing and cladding situations.
• 12mm Aesthetic flat rib
• Waterfall feature at Wall/roof join
• No swages
• Installed over plywood
• Curving- both Convex and Concave
• Most metal substrates and paint coatings
A traditional tray profile which offers superior performance in high winds, rainfall and snow
• Suitable for Drape Curving
• Ideal roof in snow conditions at low pitch
• Installed over plywood
• Suitable for use with Copper, Natural Zinc and Aluminium substrates
• Roofing application only
Displays the boldest effect of any of the Eurostyle® profiles with highly defined longitudinal lines providing light and shade variations
• Board and Batten effect
• Roofing and cladding
• Five (5) Standard pan widths
• Installed over plywood with drainage matting for air flow recommended
A seamed cap profile that offers variable shading in any roof or wall cladding application, yet providing minimalistic lines
• Can be installed without change of Pitch Flashing. (More flowing effect)
• Ideal for Convex Curving
• Particularly suitable as Copper and Natural Zinc substrate
• Installed over plywood with drainage mat for airflow recommended
Ideal cladding profile that provides a similar but slightly bolder appearance to Double Standing Seam, however is secret screw fixed and clipped together rather than seamed. Recommended maximum length 6000mm
• Ideal Cladding profile
• Installed over plywood
• Nail Strip - No clips
• Recommended maximum sheet length – 6000 mm
• Faster install
An interlocking panel available with negative detail variable recessed joint up to 15mm for soffits and wall paneling
Download the brochure below to get comprehensive profile technical information for this product
Zincalume® Steel: 0.55mm BMT, G550 Mpa Yield Stress Galvanised Steel: 0.55mm BMT, G300 or G550 Mpa Yield Stress Pre-painted Pre-painted ColorCote® or ColorSteel® 0.55mm BMT
Fixings and fasteners are to be of an approved type, compatible with all materials, the environment and meeting the requirements of the NZ Building Code. Installation is to be in accordance with E2/AS1 and the NZ Metal Roof and Wall Cladding Code of Practice.
Get in touch if outside the scope of E2/AS1
Metal Roofing & Cladding maintenance brochure
Download guideAppropriate handling and storage of profiled metal roofing and cladding, translucent and transparent roofing products plus roofing accessories is important to prevent damage which in turn will limit performance once installed. The following guidelines should be strictly followed in order to ensure the project is completed satisfactorily and meets product warranty conditions.
Download guideZincalume® Steel: 0.55mm BMT, G550 Mpa Yield Stress Galvanised Steel: 0.55mm BMT, G300 or G550 Mpa Yield Stress Pre-painted Pre-painted ColorCote® or ColorSteel® 0.55mm BMT
Below you can find the product installation guide and Building Product Information System (BPIS), available to download.
Installation GuideInstallation GuideBPIS Class 2BPIS Class 1A bold and revolutionary new commercial and residential corrugated profile arising from the respected True Oak®️ range of roofing and cladding products. Aesthetically pleasing, functional and providing many design benefits, True Oak® Deep will be viewed as a replacement for the 'fibre cement' and asbestos products of yesteryear and providing design inspiration for new builds.
Download BrochureA bold and revolutionary new Commercial and Residential Corrugated profile arising from the respected True Oak range of roofing and cladding
