Whilst aesthetics and overall appearance remain a powerful motivating factor during selection of roof type, of equal importance is the ability of the roofing product to prevent water leakage through the lapping edge, particularly on lower pitched roofs. Ribline® 800’s unique capillary lapping edge enhances performance and offers additional security against water ingress. With 800mm sheet coverage, Ribline® 800 offers the consumer, less laps, reduction in the number of fasteners, quicker installation and ultimately.... reduced costs.
Get in touchDisplays a wider effect of the seam providing a striking appearance in both roofing and cladding situations.
• 12mm Aesthetic flat rib
• Waterfall feature at Wall/roof join
• No swages
• Installed over plywood
• Curving- both Convex and Concave
• Most metal substrates and paint coatings
A traditional tray profile which offers superior performance in high winds, rainfall and snow
• Suitable for Drape Curving
• Ideal roof in snow conditions at low pitch
• Installed over plywood
• Suitable for use with Copper, Natural Zinc and Aluminium substrates
• Roofing application only
Displays the boldest effect of any of the Eurostyle® profiles with highly defined longitudinal lines providing light and shade variations
• Board and Batten effect
• Roofing and cladding
• Five (5) Standard pan widths
• Installed over plywood with drainage matting for air flow recommended
A seamed cap profile that offers variable shading in any roof or wall cladding application, yet providing minimalistic lines
• Can be installed without change of Pitch Flashing. (More flowing effect)
• Ideal for Convex Curving
• Particularly suitable as Copper and Natural Zinc substrate
• Installed over plywood with drainage mat for airflow recommended
Ideal cladding profile that provides a similar but slightly bolder appearance to Double Standing Seam, however is secret screw fixed and clipped together rather than seamed. Recommended maximum length 6000mm
• Ideal Cladding profile
• Installed over plywood
• Nail Strip - No clips
• Recommended maximum sheet length – 6000 mm
• Faster install
An interlocking panel available with negative detail variable recessed joint up to 15mm for soffits and wall paneling
Download the brochure below to get comprehensive profile technical information for this product
Zincalume® Steel: 0.40mm or 0.55mm BMT, AZ150 (150gm/m²) G550 Mpa Yield Stress Galvanised Steel: 0.40mm or 0.55mm BMT, Z450 (450gm/m²) G550 Mpa Yield Stress Pre-painted Pre-painted ColorCote and ColorSteel
Fixings and fasteners are to be of an approved type, compatible with all materials, the environment and meeting the requirements of the NZ Building Code. Installation is to be in accordance with E2/AS1 and the NZ Metal Roof and Wall Cladding Code of Practice.
Get in touch if outside the scope of E2/AS1
Metal Roofing & Cladding maintenance brochure
Download guideAppropriate handling and storage of profiled metal roofing and cladding, translucent and transparent roofing products plus roofing accessories is important to prevent damage which in turn will limit performance once installed. The following guidelines should be strictly followed in order to ensure the project is completed satisfactorily and meets product warranty conditions.
Download guideZincalume® Steel: 0.40mm or 0.55mm BMT, AZ150 (150gm/m²) G550 Mpa Yield Stress Galvanised Steel: 0.40mm or 0.55mm BMT, Z450 (450gm/m²) G550 Mpa Yield Stress Pre-painted Pre-painted ColorCote and ColorSteel
Below you can find the product installation guide and Building Product Information System (BPIS), available to download.
Installation GuideInstallation GuideBPIS Class 2BPIS Class 1Ribline® 800 prevents water leakage through a lapping edge, which is particularly important on lower pitched roofs. Whilst aesthetics and overall appearance remain a powerful motivating factor during selection of roof type, water tightness is equally as important.
